Palm Tower

Dubai
  • Facts
  • Login

    You must be a CTBUH Member to view this resource.

    Metrics
Height 231.5 m / 760 ft
Floors 53
Official Name
The current legal building name.

Palm Tower

Other Names
Other names the building has commonly been known as, including former names, common informal names, local names, etc.

St. Regis Dubai, The Palm Tower

Type
CTBUH collects data on two major types of tall structures: 'Buildings' and 'Telecommunications / Observation Towers.' A 'Building' is a structure where at least 50% of the height is occupied by usable floor area. A 'Telecommunications / Observation Tower' is a structure where less than 50% of the structure's height is occupied by usable floor area. Only 'Buildings' are eligible for the CTBUH 'Tallest Buildings' lists.

Building

Status
Completed
Architecturally Topped Out
Structurally Topped Out
Under Construction
Proposed
On Hold
Never Completed
Vision
Competition Entry
Canceled
Proposed Renovation
Under Renovation
Renovated
Under Demolition
Demolished

Completed

Completion

2020

Country
The CTBUH follows the United Nations's definition of Country, and thus uses the lists and codes established by that organization.

United Arab Emirates

City
The CTBUH follows the United Nations's definition of City, and thus uses the lists and codes established by that organization.

Dubai

Address

Palm Jumeirah

Function
A single-function tall building is defined as one where 85% or more of its usable floor area is dedicated to a single usage. Thus a building with 90% office floor area would be said to be an "office" building, irrespective of other minor functions it may also contain.

A mixed-use tall building contains two or more functions (or uses), where each of the functions occupy a significant proportion of the tower's total space. Support areas such as car parks and mechanical plant space do not constitute mixed-use functions. Functions are denoted on CTBUH "Tallest Building" lists in descending order, e.g., "hotel/office" indicates hotel function above office function.

Residential / Hotel

Structural Material
All-Steel
Both the main vertical/lateral structural elements and the floor spanning systems are constructed from steel. Note that a building of steel construction with a floor system of concrete planks or concrete slab on top of steel beams is still considered an “all-steel” structure as the concrete elements are not acting as the primary structure.

All-Concrete
Both the main vertical/lateral structural elements and the floor spanning systems are constructed from concrete which has been cast in place and utilizes steel reinforcement bars and/or steel reinforced concrete which has been precast as individual components and assembled together on-site.

All-Timber
Both the main vertical/lateral structural elements and the floor spanning systems are constructed from timber. An all-timber structure may include the use of localized non-timber connections between timber elements. Note that a building of timber construction with a floor system of concrete planks or concrete slab on top of timber beams is still considered an “all-timber” structure as the concrete elements are not acting as the primary structure.

Mixed-Structure
Utilizes distinct systems (e.g. all-steel, all-concrete, all-timber), one on top of the other. For example, a Steel Over Concrete indicates an all-steel structural system located on top of an all-concrete structural system, with the opposite true of Concrete Over Steel.

Composite
A combination of materials (e.g. steel, concrete, timber) are used together in the main structural elements. Examples include buildings which utilize: steel columns with a floor system of reinforced concrete beams; a steel frame system with a concrete core; concrete-encased steel columns; concrete-filled steel tubes; etc. Where known, the CTBUH database breaks out the materials used within a composite building’s primary structural elements.

All-Concrete

Height
Architectural
Height is measured from the level of the lowest, significant, open-air, pedestrian entrance to the architectural top of the building, including spires, but not including antennae, signage, flag poles or other functional-technical equipment. This measurement is the most widely utilized and is employed to define the Council on Tall Buildings and Urban Habitat (CTBUH) rankings of the "World's Tallest Buildings."

231.5 m / 760 ft

To Tip
Height is measured from the level of the lowest, significant, open-air, pedestrian entrance to the highest point of the building, irrespective of material or function of the highest element (i.e., including antennae, flagpoles, signage and other functional-technical equipment).
231.5 m / 760 ft
Occupied
Height is measured from the level of the lowest, significant, open-air, pedestrian entrance to the highest occupied floor within the building.
219.2 m / 719 ft
Observatory
219.2 m / 719 ft
Floors Above Ground
The number of floors above ground should include the ground floor level and be the number of main floors above ground, including any significant mezzanine floors and major mechanical plant floors. Mechanical mezzanines should not be included if they have a significantly smaller floor area than the major floors below. Similarly, mechanical penthouses or plant rooms protruding above the general roof area should not be counted. Note: CTBUH floor counts may differ from published accounts, as it is common in some regions of the world for certain floor levels not to be included (e.g., the level 4, 14, 24, etc. in Hong Kong).

53

Floors Below Ground
The number of floors below ground should include all major floors located below the ground floor level.

4

# of Apartments
Number of Apartments refers to the total number of residential units (including both rental units and condominiums) contained within a particular building.

432

# of Hotel Rooms
Number of Hotel Rooms refers to the total number of hotel rooms contained within a particular building.

290

# of Parking Spaces
Number of Parking Spaces refers to the total number of car parking spaces contained within a particular building.

571

# of Elevators
Number of Elevators refers to the total number of elevator cars (not shafts) contained within a particular building (including public, private and freight elevators).

16

Top Elevator Speed
Top Elevator Speed refers to the top speed capable of being achieved by an elevator within a particular building, measured in meters per second.

6 m/s

Tower GFA
Tower GFA refers to the total gross floor area within the tower footprint, not including adjoining podiums, connected buildings or other towers within the development.

82,258 m² / 885,418 ft²

Rankings

  • By Location
#
1003
Tallest in the World
#
143
Tallest in Middle East
#
103
Tallest in United Arab Emirates
#
86
Tallest in Dubai

Construction Schedule

2015

Proposed

2016

Construction Start

2020

Completed

Architect
Design

Usually involved in the front end design, with a "typical" condition being that of a leadership role through either Schematic Design or Design Development, and then a monitoring role through the CD and CA phases.
Gensler; RSP Architects Planners & Engineers (Pte) Ltd.
Other Consultant

Other Consultant refers to other organizations which provided significant consultation services for a building project (e.g. wind consultants, environmental consultants, fire and life safety consultants, etc).
Cost
Rider Levett Bucknall
Façade

These are firms that consult on the design of a building's façade. May often be referred to as "Cladding," "Envelope," "Exterior Wall," or "Curtain Wall" Consultant, however, for consistency CTBUH uses the term "Façade Consultant" exclusively.
Inhabit Group
Wind
Windtech Consultants Pty Ltd
Material Supplier

Material Supplier refers to organizations which supplied significant systems/materials for a building project (e.g. elevator suppliers, facade suppliers, etc).
Formwork
Doka GmbH
Sealants
Sika Services AG
Owner/Developer
Nakheel
Architect
Design

Usually involved in the front end design, with a "typical" condition being that of a leadership role through either Schematic Design or Design Development, and then a monitoring role through the CD and CA phases.
Gensler; RSP Architects Planners & Engineers (Pte) Ltd.
Architect of Record

Usually takes on the balance of the architectural effort not executed by the "Design Architect," typically responsible for the construction documents, conforming to local codes, etc. May often be referred to as "Executive," "Associate," or "Local" Architect, however, for consistency CTBUH uses the term "Architect of Record" exclusively.
Al Wasl Al Jadeed Consultants
Structural Engineer
Design

The Design Engineer is usually involved in the front end design, typically taking the leadership role in the Schematic Design and Design Development, and then a monitoring role through the CD and CA phases.
WME Consultants
MEP Engineer
Design

The Design Engineer is usually involved in the front end design, typically taking the leadership role in the Schematic Design and Design Development, and then a monitoring role through the CD and CA phases.
WME Consultants
Contractor
Main Contractor

The main contractor is the supervisory contractor of all construction work on a project, management of sub-contractors and vendors, etc. May be referred to as "Construction Manager," however, for consistency CTBUH uses the term "Main Contractor" exclusively.
National Projects and Construction LLC; Trojan General Contracting
Other Consultant

Other Consultant refers to other organizations which provided significant consultation services for a building project (e.g. wind consultants, environmental consultants, fire and life safety consultants, etc).
Acoustics
Salt Technology Services Dubai
Civil
WME Consultants
Cost
Rider Levett Bucknall
Façade

These are firms that consult on the design of a building's façade. May often be referred to as "Cladding," "Envelope," "Exterior Wall," or "Curtain Wall" Consultant, however, for consistency CTBUH uses the term "Façade Consultant" exclusively.
Inhabit Group
Fire
WME Consultants
Food Service
Tricon Foodservice Consultants Ltd.
Landscape
Cracknell
Life Safety
Tebodin
Lighting
Delta Lighting Solutions
Marketing
St. Regis Hotels & Resorts
Sustainability
Green Consulting; Global Tech; WME Consultants
Traffic
Halcrow Consulting Engineers; CH2M HILL
Vertical Transportation
Cooper & Wilcock FZ LLC
Way Finding
Limah Design Consultants
Wind
Windtech Consultants Pty Ltd
Material Supplier

Material Supplier refers to organizations which supplied significant systems/materials for a building project (e.g. elevator suppliers, facade suppliers, etc).
Formwork
Doka GmbH
Sealants
Sika Services AG

Research

22 August 2022

The World’s Highest Pools: A Deep Dive

S. Isaac Work & Shawn Ursini, Council on Tall Buildings and Urban Habitat

Tall building design has diversified and adapted to accommodate increased demand for distinctive amenities at a range of heights. Swimming pools are a classic feature...

See more

Global News

20 August 2019

Structural Work on The Nakheel Palm Tower Has Been Completed

Dubai’s Palm Tower, situated at the center of the “trunk” of the Palm Jumeirah, was visited in the wake of a recent announcement by the...



About Palm Tower

The Palm Tower, designed to be the centerpiece of Palm Jumeriah development, is a mixed-use luxury hotel and residential building destined to become an iconic landmark in Dubai’s skyline. The architectural concept was inspired by observing how a group of people gather under the protection of the shade of a palm tree. A collection of palm trees in ancient times provided a meeting point for traders, families and the community as it created a natural micro climate.

The Palm Tower, standing as a beacon in the middle of the Palm Jumeriah's entryway, flourishes as a palm leaf where the facades blossom at the top of the building. The glass facades peel off and blooms at the top to unveil “the fruit” located in the sky. The petal, which houses the highest panoramic restaurant on the Palm, will provide visitors with an exclusive dining experience in the sky. Amenities of Palm Tower's residences are also located near the building's crown, including a unique 360-degree infinity swimming pool. The facade symbolically represents the thick canopy of gorgeous bluish-green pinnate leaves that the palm tree features. Erect and ascending, the leaves are stiff and have sharp spines at their base, rising upward from the entrance of the hotel.
